Hardox 500 Plate Suppliers in India

Hardox 500 Plate Supplier

Hardox 500 Sheet Suppliers

Well known manufacturer of Hardox 500 Hot Rolled Plate, Hardox 500 Sheet, Hardox 500 Cold Rolled Plate and Hardox 500 Steel Plate in International standards.

Renowed Supplier & Exporter of Hardox 500 Wear Resistant Steel Plates, Hardox 500 Sheets, Hardox 500 Liner Plates, Hardox 500 Wear Plates, Hardox 500 Steel Plates, Welding Hardox 500 Plates .

We are stockist of HB 500 BHN Plate, HB 500 Plate, Low Temperature Hardox 500 Steel Plate, Abrasion Resistant Hardox 500 Steel Plate,Hardox 500 Abrasion Resistant Plate, Hardox 500 High Strength Plates, NM500 Wear Resistant Plates.

Aakash Steel is a well-known supplier and manufacturer of Hardox 500 Plate. We are engaged in supplying Hardox 500 Steel Plate in customizable options such as size, shape, and finishing to meet client requirements. Contact us to know the Cost of Hardox 500 Plate.

Hardox 500 Wear Plate is a weldable and bendable abrasion-resistant steel, with a nominal hardness of 500 HBW. These Hardox 500 Steel Plates are through-hardened, the minimum core hardness is 90% of the guaranteed minimum surface hardness. Our offered Hardox 500 sheet in thicknesses of 2.0 – 7.0 mm and Hardox 500 plate thickness is available in 4.0 – 103 mm. Hardox 500 steel plate is available in lengths up to 14630 mm and widths up to 3350 mm. Hardox 500 sheet is available in widths up to 1650 mm and in Inches 64.96" and lengths up to 16000 mm and in Inches 62.92".

Hardox 500 Sheets increases payload and increases service life while maintaining good toughness and processability. Hardox 500 Plate with an extra 50 Brinell hardness over our Hardox 400 grade, provides better abrasion and dent resistance as well as long wear life. Hardox 500 Wear Resistant Steel Plate have high strength and abrasion-resistant.

We are supplying a range of hardox 500 products including Welding Hardox 500 Plate. The minimal Hardox 500 Plate Hardness is 500 HBW. These Hardox 500 Steel Plates are cut to order with our High definition XPR Plasma CNC machine and on thinner sheets our fiber laser. Hardox 500 Wear Plate is mostly used in high wear-resistant applications.

With many years of experience, we are delivering high-quality Hardox 500 Sheets to a huge customer base, which offers superb cold bending and welding properties and can withstand high impact, boasting a nominal hardness of 500 HBW. Our HB 500 Plates are demanded their high-quality, reliability and durability in all environments of use. Buy high-grade Hardox 500 Plate at affordable prices.

Hardox 500 Plate Specifications

Thickness 2 – 103 mm
Length Up to 14630 mm
Width Up to 3350 mm
Hardox 500 Plate Density 8
Heat Treatment N, Q+T
Surface Paint EP, PE, HDP, SMP, PVDF

Hardox 500 Plate Equivalent Grades

CHINA GRADE CHINA STANDARD EQUAL GRDAE
JFE SSAB
NM500 GB/T 24186-2009 EH500 Hardox 500

Hardox 500 Plate Chemical Composition

Grade C *) Si *) Mn *) P S Cr *) Ni *) Mo *)
Hardox 500 Sheet 0.27 0.50 1.60 0.025 0.010 1.20 0.25 0.25
Hardox 500 Plate 0.30 0.70 1.60 0.020 0.01 1.50 1.50 0.60

Hardox 500 Plate Mechanical Properties

Grade Thickness (mm) Hardness (HBW) Typical Yield Strength (Mpa)
Hardox 500 Sheet 2.0-7.0 470-530 1400
Hardox 500 Plate 4.0-32.0 470-530 1400
Hardox 500 Plate 32.1-103.0 450-540 1400

Hardox 500 Sheet Plate Maximum Carbon equivalent CET (CEV)

Thickness mm Sheet
2.0-7.0
Plate
4.0-13.0
Plate
13.0-19.9
Plate
20.0-39.9
Plate
40 – 130
CET (CEV) Max 0.38 (0.49) 0.38 (0.53) 0.43 (0.64) 0.45 (0.66) 0.47 (0.75)
CET (CEV) Typical 0.33 (0.45) 0.37 (0.51) 0.41 (0.63) 0.41(0.63) 0.43 (0.72)

Prime Countries Where We Supply & Export Abrasion Resistant Hardox 500 Sheet Plate

Afghanistan Algeria Angola
Argentina Australia Austria
Azerbaijan Bahrain Bangladesh
Belarus Belgium Bhutan
Bolivia Brazil Bulgaria
Canada Chile China
Colombia Costa Rica Croatia
Czech Republic
Denmark Ecuador Egypt
Estonia Finland France
Gabon Ghana Greece
Hong Kong Hungary India
Indonesia Iran Iraq
Israel Italy Japan
Jordan
Kazakhstan Kenya Kuwait
Lebanon Libya Lithuania
Malaysia Mexico Mongolia
Morocco Netherlands New Zealand
Nigeria Norway Oman
Pakistan Peru Philippines
Poland Portugal Qatar
Romania Russia
Saudi Arabia Serbia Singapore
Slovakia South Africa South Korea
Spain Sri Lanka Sweden
Switzerland Taiwan Thailand
Trinidad & Tobago Tunisia Turkey
Ukraine United Arab Emirates (UAE) United Kingdom (UK)
United States (US) Venezuela Vietnam
Yemen
Aberdeen Abu Dhabi Afghanistan
Ahmedabad Ahvaz Al Jubail
Al Khobar Algiers Ankara
Atyrau Bangkok Bengaluru
Bhopal Bogota Brisbane
Busan Cairo Calgary
Caracas Chandigarh Chennai
Chiyoda Coimbatore Colombo
Courbevoie Dallas Dammam
Doha Dubai Edmonton
Ernakulam Faridabad Geoje-si
Gimhae-si Granada Gurgaon
Hanoi Haryana Ho Chi Minh City
Hong Kong Houston Howrah
Hyderabad Indore Istanbul
Jakarta Jeddah Karachi
Kolkata Kuala Lumpur Kuwait City
La Victoria Lagos Lahore
London Los Angeles Ludhiana
Madrid Manama Melbourne
Mexico City Milan Montreal
Moscow Mumbai Muscat
Navi Mumbai New Delhi New York
Noida Perth Petaling Jaya
Pimpri-Chinchwad Port-of-Spain Pune
Rajkot Rio de Janeiro Riyadh
Santiago Secunderabad Seoul
Sharjah Singapore Surat
Sydney Tehran Thane
Thiruvananthapuram Toronto Ulsan
Vadodara Visakhapatnam Vung Tau

Hardox 500 Wear Steel Plate Used in

After inspection care is taken towards packing, before dispatching HB 500 plate, Hardox 500 Sheets across through strict quality tests and delivered to their respective customers worldwide. We focus on every procedure to assure quality of Hardox 500 steel pate. We offers just about everything to meet your Hardox 500 Sheets and Hardox 500 Plates pack requirements to industry.
